643035 35 Amp 32Vdc Manual Reset Push to Trip Breaker

643035 35 Amp 32Vdc Manual Reset Push to Trip Breaker

• Designed for accessory circuits in RVs, boats, specialty vehicles, and fleet equipment, this panel-mount breaker provides up to 60A of DC protection and meets ABYC interrupt rating requirements for large battery banks.
• Its panel-mount design installs cleanly through a cutout for a flush, accessible fit on dashboards or control panels.
• Waterproof and ignition-protected for marine engine compartments, it meets SAE J1171 and ABYC standards and conforms to SAE J553 performance requirements.

• Voltage Rating: 32VDC
• Reset Type: Type III - Manual Reset - Push-to-Trip
• Interrupting Rating: 2500A @ 32VDC (ABYC E-11)
• Operation Temperature: -40° F ~ 185° F
• Testing: SAE J553, ABYC E-11
• Mid Range - Waterproof Circuit Breaker
• Terminals Configuration: #10-32 Stud
• Mounting Type: Panel Mount; #8-32 threaded inserts
• Ignition Protected: SAE J1171 | Waterproof IP66
