SCD30S24-UDN 30W 24V 1.3A DC/DC Converter

SCD30S24-UDN 30W 24V 1.3A DC/DC Converter

These units regulate voltage for sensitive electronic equipment run from battery power. For example, a 24 Vdc battery system where the battery voltage can be 30 volts, sometimes higher during charging, and dip below 22 volts under heavy load. The SCD can be used to stabilize the voltage for those devices not designed to handle wider voltage swings.

They are also a convenient and inexpensive alternative to running AC power through a large industrial machine. The SCD can use 24 Vdc commonly available on many parts of the machine to create other voltages needed to run sensors, transducers and other devices that the machine requires to work properly

• 30W Switching DC Power Supply
• Input Voltage: 20-72Vdc
Features
• DIN Rail or Chassis Mount by removing DIN clips
• Rugged, encapsulated design to resist environment
• IP20 protection
• Wide 20 to 72 Vdc input range
• M3 screw clamp terminations
• Simple snap-on for DIN Rail TS35/7.5 or TS35/15
• Galvanic isolation
• Five year limited warranty
