RLY230 Cube Timer 95-145AC Delay On Operate Binary Switch Timing Adjustment

RLY230 Cube Timer 95-145AC Delay On Operate Binary Switch Timing Adjustment

Delay on Operate - the delay period begins when input voltage is applied.  At the end of the delay period, the relay will operate and will not release until input voltage is removed.  Reset occurs when the voltage is reapplied.

Features

• 2 x 2 Industry Standard Package
• Binary Switch Programmable
• 1 Amp Max - 40mA Min
• 95-145 Volts AC or DC Operation
• 1 to 1023 Seconds Timing Range
• .250 inch Quick Disconnect Terminal
